TFG-K
TFG-K is a self extracting grinding table with an integrated fan and cartridge filtration system for capturing dust and fumes directly at the workstation.
Self extracting grinding table
Models: TFG-K 800, 1300, 1600 and 2400
Maximum airflow: 5,900 m³/h
Need help selecting the right table size? Call +385 (0)31 701 211 and our team will help you choose the right TFG-K model.
Product description
Integrated Extraction and Filtration
TFG-K combines a robust industrial worktable with an integrated extraction fan and cartridge filtration system. Dust and fumes generated during welding, grinding and deburring are captured directly at the workstation. Automatic Pulse Jet cleaning maintains filter performance, while the spacious working area and openable side sections accommodate different workpiece sizes.
Technical data
Specifications
The values presented are indicative and refer to the standard configuration. Final performance parameters are determined based on your process requirements and the number of workstations.
| Motor power | 4 kW |
|---|---|
| Voltage | 400 V |
| Rated frequency | 50 Hz |
| Maximum air flow | 4000 m³/h |
| Pressure | 2000 Pa |
| Number of filter cartridges | 1 |
|---|---|
| Sound level | ≤ 75 dB(A) |
| Working surface (W × L) |
870 × 825 mm |
| Dimensions (W × D × H) |
1537 × 1540 × 1436 mm |
| Motor power | 4 kW |
|---|---|
| Voltage | 400 V |
| Rated frequency | 50 Hz |
| Maximum air flow | 4700 m³/h |
| Pressure | 2000 Pa |
| Number of filter cartridges | 2 |
|---|---|
| Sound level | ≤ 75 dB(A) |
| Working surface (W × L) |
1370 × 825 mm |
| Dimensions (W × D × H) |
2073 × 1540 × 1683 mm |
| Motor power | 4 kW |
|---|---|
| Voltage | 400 V |
| Rated frequency | 50 Hz |
| Maximum air flow | 4700 m³/h |
| Pressure | 1980 Pa |
| Number of filter cartridges | 2 |
|---|---|
| Sound level | ≤ 75 dB(A) |
| Working surface (W × L) |
1670 × 825 mm |
| Dimensions (W × D × H) |
2373 × 1540 × 1683 mm |
| Motor power | 4 kW |
|---|---|
| Voltage | 400 V |
| Rated frequency | 50 Hz |
| Maximum air flow | 5900 m³/h |
| Pressure | 1750 Pa |
| Number of filter cartridges | 2 |
|---|---|
| Sound level | ≤ 75 dB(A) |
| Working surface (W × L) |
2470 × 825 mm |
| Dimensions (W × D × H) |
3173 × 1540 × 1683 mm |
Advantages
Why TFG-K
Download
Documentation
Technical documentation and certificates
Are you interested in TFG-K?
Tell us about your process, workpiece dimensions and required working surface, and our team will recommend the right TFG-K model and prepare a tailored quote.
